PRODUCT RANGE
Sizes NPS 2 to NPS 48
Class 150 to Class 2500
Class 150 to Class 2500
MATERIALS
Available Forged (A105, A182 F304, F304L, F316, F316L, F51, F53, A350 LF2, LF3, LF5,) Casting (A216 WCB, A351 CF3, CF8, CF3M, CF8M, A995 4A, 5A, A352 LCB, LCC, LC2) Monel, Inconel, Hastelloy
DESIGN FEATURES
Full or Reduced Bore
RF, RTJ, BW or PE
Side entry, top entry, or welded body design
Double Block & Bleed (DBB)，Double Isolation & Bleed (DIB)
Emergency seat and stem injection
Anti-Static Device
Anti-Blow out Stem
Cryogenic or High Temperature Extended Stem
RF, RTJ, BW or PE
Side entry, top entry, or welded body design
Double Block & Bleed (DBB)，Double Isolation & Bleed (DIB)
Emergency seat and stem injection
Anti-Static Device
Anti-Blow out Stem
Cryogenic or High Temperature Extended Stem
DESIGN STANDARD
Design & manufacture according to API 6D, API 608, ISO 17292
Face-to-face according to API 6D, ASME B16.10
End Connection according to ASME B16.5, ASME B16.47, MSS SP-44 (NPS 22 Only)
Test & inspection according to API 6D, API 598
Fire safe design according to API 6FA, API 607
Also available per NACE MR-0175, NACE MR-0103, ISO 15848
Face-to-face according to API 6D, ASME B16.10
End Connection according to ASME B16.5, ASME B16.47, MSS SP-44 (NPS 22 Only)
Test & inspection according to API 6D, API 598
Fire safe design according to API 6FA, API 607
Also available per NACE MR-0175, NACE MR-0103, ISO 15848
